LRES4006MT-POE
1. It is a PCI express x4 4-port M12 interface PoE+ Gigabit ethernet image capture card.
2. It is compatible with PCIe X8 and X16 channels.
3. It is very suitable for wet and other harsh environment, such as field monitoring, railway monitoring, industrial production, etc.
4. It uses a unique X-Codede cross shield to isolate four communication signals for signal integrity.
2. It is compatible with PCIe X8 and X16 channels.
3. It is very suitable for wet and other harsh environment, such as field monitoring, railway monitoring, industrial production, etc.
4. It uses a unique X-Codede cross shield to isolate four communication signals for signal integrity.
Khuyến mãi khi mua ONLINE hoặc gọi Hotline
LRES4006MT-POE is a PCI Express x4 4-port M12 interface PoE+ gigabit ethernet image capture card independently developed by Linkreal Co., Ltd. on the basis of Intel master control scheme, compatible with PCIe x8 and x16 channels at the same time.
The LRES4006MT-PoE is developed on Intel 4-port ethernet MAC+PHY (Media Access Controller and Physical Interface Transceiver) controllers that allow four ports to operate in full duplex mode at the highest point in gigabit Ethernet connections to accommodate high-performance network communications. Link aggregation can be used to expand bandwidth and save PCI Express channel resources without using bus bandwidth.
The LRES4006MT-PoE uses a unique X-Code cross shield to isolate four communication signals for signal integrity, while its rugged and durable characteristics make the modified product ideal for wet and other harsh environments, such as field monitoring, railway monitoring, industrial production, etc.
PCIe x4 Quad-port PoE+ M12 Gigabit Vision Frame Grabber Card: LRES4011MT-PoE
Specifications
Controller | Intel Chip |
Baffle Height | Half and full height baffles |
Power Consumption | 5.0W |
PoE power/port | 30W |
Total output power | 60W/Sum; The PoE+ power consumption when the four ports are used at the same time is 15.5W/port (Max) |
System Support | Windows XP/Vista7/8/8.1/10 |
Windows Server 2003 R2/2008 R2/2012 R2/2016 R2/2019 R2; | |
Linux Stable Kernel version 2.6.32.x/3.x/4.x or later; | |
Linux CentOS/RHEL 6.x / 7.x or later; | |
Ubuntu 14.x/15.x/16.x or later; | |
VMware ESX/ESXi 4.x/5.x/6.x or later | |
Bus Type | PCIe v2.1 x4，compatible with x8、x16 |
Data rate | 10/100/1000MbE |
Connector | 4*1G M12 X-code |
Technical Features
Protocol Support | IEEE802.3at -2009 PoE standard IEEE802.3af -2003 PoE standard IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3z IEEE 802.1Q VLANs IEEE 802.3x IEEE 1588 IEEE 802.3az – Energy Efficient Ethernet (EEE) |
iSCSI | No |
WoL | No |
Jumbo Frames | YES |
DPDK | Yes |
PXE | Yes |
FCoE | No |
Environment Features
Operating Temperature | 0 ℃ to 55 ℃ (32 ℉ to 131 ℉) |
Storage Temperature | -40 ℃ to 85 ℃ (-40 ℉ to 185 ℉) |
Storage Humidity | Maximum: 90% non-condensing relative humidity at 35 ℃ |
Physical Features
Size(mm) | 160*120*21 |
Weight(g) | * |
LED Indicators
LED Indicators | POE: Green |
1000Mbps:Yellow Link + Green Blink | |
100Mbps: Green Blink 10Mbps, No |
P/N | Description |
LRES4006MT-POE | PCIe x4 Quad Port PoE+ M12 Gigabit Vision Frame Grabber Card (Intel Chip Based) |
PS: Above details are only for reference, if there is any change,no prior notice.
-
