Đặc điểm nổi bật:

Part Number	MDDLN45SE
Product	Servo Driver
Details	A6SE series Position control type (Incremental system only, Pulse train only) without the safety function
Product Name	MINAS A6S Series Servo Driver
Features	Swifter, smarter and easier to use Powered Up compact driver

Bộ điều khiển Servo Panasonic MDDLN45SE

Name: Bộ điều khiển Servo Panasonic MDDLN45SE
Brand: THIẾT BỊ TỰ ĐỘNG HÓA ANTECH
SKU: 2051
Availability: InStock
Rating: 5 (1 reviews)

Khuyến mãi khi mua ONLINE hoặc gọi Hotline

1 Miễn phí vận chuyển toàn quốc
2 Miễn phí khảo sát tư vấn
3 Áp dụng cho khách hàng gọi điện, đến trực tiếp hoặc chát!

Yêu cầu gọi lại Gọi điện xác nhận và nhân viên tư vấn ngay

Category: PANASONIC Tags: MDDLN45SE, panasonic, servo

Thông tin chi tiết

Spec Detail

Specifications and design of the products are subject to change without notice for the product improvement.

Item	Specifications
Part Number	MDDLN45SE
Product details	A6SE series Position control type (Incremental system only, Pulse train only) without the safety function
Family Name	MINAS A6
Series	A6SE series
Type	Position control type
Frame	D-Frame
Frequency response (kHz)	3.2
Control method	Position control
About control method	A6SE series driver (Position control only) does not correspond to the absolute system of using the serial communication with the host device. It supports incremental system only.
Safety Function	without
Supply voltage	Single/3-phase 200 V
I/F Classification of type	Pulse train only
Dimensions (W) (Unit: mm)	85
Dimensions (H) (Unit: mm)	150
Dimensions (D) (Unit: mm)	170
Mass (kg)	2.1
Environment	For more details, please refer to the instruction manual.

Basic Specifications

Item	Specifications
Input power: Main circuit	Single/3-phase 200 V (+10% -15%) to 240 V (+10% -15%) 50/60 Hz
Input power: Control circuit	Single phase 200 V (+10% -15%) to 240 V (+10% -15%) 50/60 Hz
Encoder feedback	23-bit (8388608 resolution) absolute encoder, 7-wire serial
About Encoder feedback	* Since it can be used only as an incremental system, do not connect the battery for absolute encoder. Parameter Pr. 0.15 must be set to “1” (factory settings).
Parallel I/O connector: Control signal Input	General purpose 10 inputs The function of general-purpose input is selected by parameters.
Parallel I/O connector: Control signal Output	General purpose 6 output The function of general-purpose output is selected by parameters.
Parallel I/O connector: Analog signal Output	2 outputs (Analog monitor: 2 output)
Parallel I/O connector: Pulse signal Input	2 inputs (Photo-coupler input, Line receiver input)
Parallel I/O connector: Pulse signal Output	4 outputs (Line driver: 3 output, open collector: 1 output)
Communication function	USB
Communication function: USB	USB interface to connect to computers for parameter setting or status monitoring.
Regeneration	Built-in regenerative resistor (external resistor is also enabled.)
Control mode	Switching among the following 3 mode is enabled, (1) Position control, (2) Internal velocity command, (3) Position/Internal velocity command

Dimensions

Specifications and design of the products are subject to change without notice for the product improvement.
[Unit: mm]

* The dimension is for the A6SF Series, but outer dimension is the same as the A6SE and A6SG Series. Please refer to the catalog for detail dimension.
* The air flow direction of the fan is shown on the external dimension of the driver in the catalog.

Connector specification

Specifications and design of the products are subject to change without notice for the product improvement.
